Regulator



REGULATOR -  MODEL 713

Regulator, Model 713

- Series: 700 / Model: 713 Regulator

- Type: constant flow (0.3 liter / min)

- Max inlet pressure: 35.5 bar / Min outlet pressure: 1.4 bar

- Gauge: 0 - 35 bar

- Connector: CGA 600; 3/18" / 4.8mm

- Used for: 7HP (34 liter)

- Made in CALGAZ, USA









REGULATOR -  MODEL 715

Regulator, Model 715

- Series: 700 / Model: 715 Regulator

- Type: constant flow (0.5 liter / min)

- Max inlet pressure: 70 bar / Min outlet pressure: 4.1 bar

- Gauge: 0 - 70 bar

- Connector: 5/8-18 UNF; 3/16" / 4.8mm

- Used for: 2AL; 8AL; 6D; 10AL

- Made in CALGAZ, USA











REGULATOR - SERIES 2000, MODEL 2001

Regulator, Model 2001

- Series: 2000/ Model: 2001 Regulator

- Typw: flow on demand, suitable for gas detector with a suction pump

(0-3 liter/ min)

- Gauge: 0 - 70 bar

- Connector: 5/8 UNF C10 ; 3/16" / 4.8mm

- Used for: 2AL; 8AL; 6D; 10AL

- Made in CALGAZ, USA











REGULATOR - MODEL R21

Regulator, Model R21

- Series: R21 Regulator

- Function: for high pressure regulator

- Inlet pressure: 3.5 - 7 bar

- Gauge: 0 - 4000 psi

- Connector: 1/4 NPT (Female)

- Used for: CALGAZ 10ST, 10AL

- Made in CALGAZ, USA
